  • High Precision Wedge Wire Screen Filter Pipe
Product Name:

High Precision Wedge Wire Screen Filter Pipe

Product features

Wedge wire screen also named as stainless steel V  shaped wire screen, Johnson screen , Water well screen, Rod based wire wrapped screen, Wedge wire screen pipe etc.

Product Parameter

Characteristics:



1. Many varied applications in sieving, sorting and separating.

2. Wedge Wire surface is self-cleaning.

3. Various construction types:From outside to inside, or from inside to outside.

4. Wedge Wire on Vee shaped bars for light duty.

5. Wedge Wire on fins for medium or heavy duty.

6. Grates edged with flat bar or angle.

7. Highly polished grates for wet areas, bars or bench tops.

8. Heavy grids and support bar systems for absorption vessels.

9. Grates and grids made as single or multi-part items.

10. Materials to suit applications (Stainless steel 304 or 316, mild steel etc)




configuration

Wedge Wire Johnson Screen Filter
Specification (Profile wire):Width(mm): 1.0 1.2 1.5 2.0 2.2 3.0 3.2
Height(mm): 2.0 2.5 3.5 4.6 5.0 6.0
Specification (support rods):Width(mm): 2.0 3.0
Height(mm): 3.0 4.6 5.0 6.0 7.0
Round: From 2.50mm to 6.0mm
Note: other wires and rods available upon request
Slot size0.10, 0.15, 0.20, 0.25, 0.30…… 100mm also achieved upon request.
Material:Stainless steel 304, 304L, 316L ,321 etc.)
LengthUpto 4 meters
Diameter29-1200mm
Screen endPlain beveled ends, male/female threaded, flange, close up.
Other sizes available on request.
Advantage Reduce energy consumption and increase water flow.Reduce erosion of entry surfaces and increase well life.Allow a uniform and efficient well development.Reduce significantly potential pump damage and subsequent maintenance costs.
